Examples of Covert Camera images

Here are a few examples of images captured using covert CCTV cameras,
(test recorded on VHS), which Doktor Jon thought you might find of interest:-

Corridor viewing camera

The high resolution colour camera
was fitted with a 25mm lens (2x
magnification), and then 24Hour
recorded onto a dedicated VHS
Time Lapse Video Recorder
Picture quality was about 25%
better during daylight hours.

Desk viewing camera

The high resolution colour camera
was fitted with a 4mm pinhole lens
wide angle), and then 24Hour
recorded onto a dedicated S-VHS
Time Lapse Video Recorder.
Picture quality was about 50%
better during daylight hours.
(this image taken from VHS recording)

Corridor viewing camera

The high resolution colour camera
was fitted with a 25mm lens +x2
extender=x6 mag), and then 24Hour
recorded onto a dedicated VHS
Time Lapse Video Recorder
Picture quality was about 30%
better during daylight hours.

More Covert Pictures >>>
