Examples of Covert Camera images

Here are a few examples of images captured using covert CCTV cameras,
(test recorded on VHS), which Doktor Jon thought you might find of interest:-

Room viewing camera

The high resolution colour camera
was fitted with a 9mm pinhole lens
slight w/angle), and then 24Hour
recorded onto a dedicated VHS
Time Lapse Video Recorder
Picture quality was about 10%
better during dark hours.

Path viewing camera

The high resolution colour camera
was fitted with a 25mm telephoto lens
(x3 magnification), and then 24Hour
recorded onto a dedicated VHS
Time Lapse Video Recorder
Picture quality was about 25%
lower under night lighting.

Corridor viewing camera

The high resolution colour camera
was fitted with a 6.2mm pinhole lens
wide angle), and then 24Hour
recorded onto a dedicated VHS
Time Lapse Video Recorder
Picture quality was about 20%
better during daylight hours.
